Food Fluidized Bed Granulation Process And Drying Machine Fluid Bed Dryer Processor

Name: Food Fluidized Bed Granulation Process And Drying Machine Fluid Bed Dryer Processor
Brand: SNYNXN
SKU: FL 60
Rating: 4.8 (146 reviews)

Product Details:

Place of Origin:	JIANGSU CHINA
Brand Name:	SNYNXN
Certification:	CE ISO GMP
Model Number:	FL 60

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	NEGOTIABLE
Packaging Details:	Film wrapping, wooden case.
Delivery Time:	60 DAYS
Payment Terms:	T/T, L/C
Supply Ability:	100 SETS/ YEAR

Contact Now

Detailed Product Description

Machine Name:	FL-60 Fluid Bed Drying Granulator	Batch Output:	30 - 90 Kg/batch
Power Of Supply Liquid Motor:	0.37 Kw	Processing Raw Material:	Powder Or Granules Of Pharmaceutical, Food, Chemical Industrial
Key Selling Points:	One Step Automatic	Place Of Origin::	Jiangsu, China
Machine Videos:	Available	After-sales Service Provided:	Online Support, Engineers Available To Service Machinery Overseas, Field Installation, Commissioning And Training, Video Technical Support, Field Maintenance And Repair Service
High Light:	food fluidized bed granulation process , 90kg/batch fluidized bed granulation process , 30kg/batch fluid bed dryer processor

Name: FL-60 Fluid Bed Drying Granulator as Fluid Bed Equipment

Factory Manufacturer Fluid Bed Granulating And Drying Machine Fluid Bed Equipment

Description:

The machine is suitable for drying and granulating damp granule or powder material in many fields such as pharmaceutical industry, chemical industry, feed stuff industry, light industry, etc. It is suitable for drying big granule, small mass, viscosity, black material produced by damp method mixer gratulatory, giant arum, acrylic acid amide, etc. Materials which have big volume change.

Pharmaceutical industry: Granules used in tablet, capsule, electuary.

Foodstuff: cocoa, coffee, milk powder, granules of juice, flavor and so on.

Other industries: pesticide, feed, chemical fertilizer, pigment, dyestuff and so on

Drying: powder or granule state of wet material

Granulating function.

Working principle and Advantages:

After being heated and purified, air comes up to a certain temp. and is taken to container by air motor, then through screen plate under the action of stirring and negative pressure, forming fluid, connecting between large area air and solid. The water of material (solid) is vaporized rapidly and taken away by air exhaust pipe, then reach the standard of drying the material. Fine powder flying off during dying process is collected by bag filter, then return to Fluid bed through ash removal device.

1)Through powder granulating, the flow property is improved and the dust is reduced.

2) Thtough powder granulating, its solving property is improved.
3) The mixing, granulating and drying processes can be completed in one step inside the machine.
4) The operation of equipment is safe, because the anti-static filtering cloth is adopted.
5) Operation personnel cannot be damaged if explosion takes place, because there is releasing hole.
6) Has no dead corner. Therefore the loading and unloading are quick, light and clean.
7) Meets the requirements of GMP.

Technical Parameters:

Item			specification
Name		Unit	60	120	200	300	500	800-1000
Container Volume		L	220	420	670	1000	1500	By client
Diameter		mm	1000	1200	1400	1600	1800
Capacity		kg/batch	60	120	200	300	500
Steam	Pressure	Mpa
Steam	Consumption	kg/h	120	140	180	310	400
Power of fan		kw	11	18.5	22	30	45
Power of supply liquid motor		kw	0.37
Compressed air	Pressure	Mpa	0.4-0.6
Compressed air	Consumption	m 3 /min	0.9	0.9	1.1	1.1	1.5
Working temperature		℃	Normal temperature -120℃ could adjust
Noise		DB	Installed separated with fan ≤75
Overall dimension of machine		mm	Installation drawing or customer’s room

Food Fluidized Bed Granulation Process And Drying Machine Fluid Bed Dryer Processor 0

Food Fluidized Bed Granulation Process And Drying Machine Fluid Bed Dryer Processor 1

OUR FACTORY:

Food Fluidized Bed Granulation Process And Drying Machine Fluid Bed Dryer Processor 2

Food Fluidized Bed Granulation Process And Drying Machine Fluid Bed Dryer Processor 3

Company Information:

SNYNXN pecializes in R&D, manufacturing, operation, export and related services of rotary flash dryers, centrifugal spray drying equipment, vibrating fluidized bed dryers, etc. The production base is located in Jiangyin City, Jiangsu Province,China. Equipment designed over the years has been involved in the fields of medicine, chemicals, pesticides, electronics, mining, food, dyes, pigments and so on. The market is spread over 20 countries. Our company has a group of capable engineers and senior management personnel with more than ten years of work experience, also has a group of excellent production personnel. They have excellent capabilities in research, design, service, etc.

Food Powder Spray Granulating Machine Coffee Drying Powder Fluid Bed Dryer Granulator in Pharmaceutical Industry

Service and Gurantee:

We sincerely invite you to be our long term relationship friend, and we always prepared to provide our best services for you and would like you to know below we want to present :

l 1. Each machine is manufactured by professional experienced staff.

l 2. 12 months warranty + 100% QC inspection Before Shipment.

l 3. Overseas services provided. Technicians can be sent to spot for guiding the installation and debugging. Training operators and accomplish the commissioning.

l 4. Consultant services for whole machine life, 24 hours technical support by email and phone.When warranty date expired, lifetime maintenance service is provided and at buyer’s cost.
