GHL Pharmaceutical Shear High Speed Mixer Granulator RMG Powder Granulation Machine

Name: GHL Pharmaceutical Shear High Speed Mixer Granulator RMG Powder Granulation Machine
Brand: SNYNXN
SKU: GHL 400
Rating: 4.5 (110 reviews)

Product Details:

Place of Origin:	JIANGSU CHINA
Brand Name:	SNYNXN
Certification:	CE ISO GMP
Model Number:	GHL 400

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Film Wrapping, Wooden Box
Delivery Time:	WITHIN 50 DAYS
Payment Terms:	T/T, L/C
Supply Ability:	100 SET/ YEAR

Contact Now

Detailed Product Description

Machine Type:	GHL Series High Speed Shear Granulators	Processing Materials Type:	Granules
Volume:	Depending On Model (5-1500L)	Capacity:	1 - 500 (kgs/Batch)
Key Selling Point:	Competitive Price	Voltage:	220V/380V/415V/600V
Mixing Power:	1.1-55Kw	Core Components:	Engine, Bearing, Motor (1 Year Warranty)
Marketing Type:	Brand New, IN STOCK	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
High Light:	GHL High Speed Mixer Granulator , Pharmaceutical Shear High Speed Mixer Granulator , RMG powder granulation machine

Description: Wet Mixing Fertilizer Powder Granulation RMG Machine

GHL Pharmaceutical Shear Rapid Mixer Granulator Wet Mixing Fertilizer Powder Granulation RMG Machine

GHL WET MIXING GRANULATOR

1, GHL Series is the new type pharmaceutical machinery, designed on the basis of adopting the principle of one-step granulator. It can blend and mix the dry powder rapidly, then the even wet powder and granulator. It meets the requirements of GMP Standard.

2,It can be widely used in pharmaceutical industry, chemical industry, foodstuff industry, powder metallurgy, cosmetic industry, dying stuff industry, and so on.

3,The advantages: high efficient; fast; even; mixing and granulating in the same chamber.

Working Principle

Blending wheel has three leaves with special shape, which is rotated with a certain speed driven by the gearing to make the material moving regularly. So it can mix the raw material efficiently. The mixed wet material is cut into even particles in a short time by the high speed rotary cutter The process of mixing, wetting and granulating go on automatically and continuously within ten minutes.

Product Paramenters

Type	GHL-50	GHL-150	GHL-200	GHL-250	GHL-300	GHL-400
Volume (L)	50	150	200	250	300	400
Capacity (kg/batch)	15	50	80	100	130	200
Blending speed (rpm)	300/210	270/180	270/180	188/130	160/110	120/85
Blending power (KW)	4/5.5	9/11	11/14	11/14	11/14	15/17
Cutting power (KW)	1.5/2.2	2.4/3	3.3/4	3.3/4	4.5/5.5	6.5/8
Cutting speed (rpm)	1440/2900
Working time (min)	8-15
Particle size (mesh)	20-80

GHL Pharmaceutical Shear High Speed Mixer Granulator RMG Powder Granulation Machine 0

CERTIFICAITONS:

GHL Pharmaceutical Shear High Speed Mixer Granulator RMG Powder Granulation Machine 1

EXHIBITIONS:

GHL Pharmaceutical Shear High Speed Mixer Granulator RMG Powder Granulation Machine 2

OUR FACTORY:

GHL Pharmaceutical Shear High Speed Mixer Granulator RMG Powder Granulation Machine 3

FAQ

ARE YOU REAL FACTORY OR TRADING COMPANY?

YES ! We are real and most reliable factory here. Welcome you visit us anytime! After compare , you will know we are most expert and big factory in this !

WHAT MACHINE YOUR COMPANY HAVE? CAN CUSTOMIZED MACHINE UPON MY NEEDS?

Yes, we also produce CRUSHER, GRINDER, MIXER, DRYER, GRANULATOR, VIBRATING SIFTER, CONVEYOR, etc.

We absolutely can customized machine upon your side, just freely tell me your needs or design request, i will check and give you quote.

CAN YOU GIVE ME GUIDE ON OTHER MACHINE ? TO FULL MY PRODUCTION LINE

YES ! Our company have build more than 20years now, we also can recommend you other machine supplier which we don't sale , like packing machine, filling machine, etc !!

HOW TO VISIT YOUR COMPANY?

Our company is in WUXI city, near shanghai city, only 90mins away from Shanghai Hongqiao Airport.
Or you can call me +86 13921367085 anytime you arrive Shanghai, I will pick you up.

WHAT'S YOUR BEFORE & AFTER SERVICE ?

1) Professional advice and rich experience help to choose machine.

2) Longtime maintainance and considerate technical support

3) Technicians can be sent to abroad to install.

5)ONE year guarantee. WHOLE life service. Within1 year, any problem part can send to us, we can give provide free new part(only

damaged by machine itself).

4) Any problem before or after delivery, you could find and talk with us anytime. We will free supply technical support.

5) Video / CD of test running and installation, Maunal book, tool box sent with machine if client request.

WHAT'S YOUR SHIPPING ITEM PROCESS?

We have long-term working shipping forwarder. We can do our best to send machine to your port safe and sound .

If your need , we can help you do custom clearance .

Packaging Details: 1. Outside package: Standard export wooden cases.

2. Inner package: Stretch film.

Delivery Details: Machine will be finished in about 35 workdays after payment.

HOW ABOUT YOUR PAYMENT TERM?

1. Normally we can work on T/T or L/C.

2. On T/T term, 30% down payment is required in advanced. And 70% balance shall be settled before shipment.

3. On L/C term, a 100% irrevocable L/C without soft clause can be accepted.Please seek the advice from the individual sales manager whom you work with.

5) Video / CD of test running and installation, Maunal book, tool box sent with machine
