Stainless Steel Cone Mill Pellet Machine 8mm 316SS 2500KG / H

Product Details:

Place of Origin:	JIANGSU CHINA
Brand Name:	SNYNXN
Certification:	CE ISO GMP
Model Number:	KZL 125

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	Standard Export Packing in Wooden case
Delivery Time:	IN 30 DAYS
Payment Terms:	T/T, L/C
Supply Ability:	100 sets / year

Contact Now

Detailed Product Description

Type:	Grinding Granulator Machine	Capacity:	20-2500 KG/H
Screen Diameter:	1-8mm	Function:	Granulating Size Reduction
Raw Material:	Stainless Steel 304/316SS	Core Components:	Engine, Bearing, Gearbox, Motor, Gear
Voltage:	Customized, 220V/380V, 380V, 110V/220V, 220V	After Warranty Service:	Video Technical Support, Online Support, Spare Parts
Highlight:	Stainless Steel Cone Mill Pellet Machine , 8mm Cone Mill Pellet Machine , 2500 KG/H Cone Mill Pellet Machine

Description of KZL series Medicine Powder fast Grinding Granulator

High Speed Granulator KZL Type 250 Stainless Steel Cone Mill Manufacturer

Suitable for crushing and recycling in medicine, food, chemical pigments, fertilizer ,etc. In operation, a high speed rotating knife cut the particles with different shapes and specificstions. Material particle size smaller than the screen passes to the discharge while the larger particles are reduced. This equipment can replace YK swaying granulator in some cases.
Stainless Steel Cone Mill Pellet Machine 8mm 316SS 2500KG / H 0
Model Features:
1.Table type: Widely used in crushing and pelletizing of non uniform materials.
2.Inclined type: Normal type,suitable for lighter proportion materials granulation. Popular used in small batch production.
3.Pipeline type: Pipeline connection, either single or joint use is abailable. No dust when used in combination.

Technical Parameter

KZL PIPELINE TYPE HIGH SPEED GRANULATOR
Model	160	180	200	250
Spring Length(mm)	120	135	140	180
Screen Diameter(mm)	1-8	1-8	1-8	1-8
Capacity(kg/h)	150-300	150-400	200-500	300-1000
Motor Power(kw)	1.5	1.5	1.5-2.2	2.2-3
Rotation Speed	Frequency 200-1500r/min or 400-300r/min
Overall Dimension(mm)	10007201170	10507201200	11007501300	13508001550
Approx. Weight(kg)	140	160	190	260

Stainless Steel Cone Mill Pellet Machine 8mm 316SS 2500KG / H 1

Working Principle

Adding raw material from feeding hopper and fixing the granulating knives. The material goes into the sieve room and touches screen mesh of high rotating speed. The fixed granulating knives crush larger particles by centrifugal force. The whole progress is finished when the required material put out.

Stainless Steel Cone Mill Pellet Machine 8mm 316SS 2500KG / H 2

Stainless Steel Cone Mill Pellet Machine 8mm 316SS 2500KG / H 3

Stainless Steel Cone Mill Pellet Machine 8mm 316SS 2500KG / H 4

Company Profile

SNYNXN is a high-tech enterprise mainly engaged in the research, development, production and sales of Pharmaceutical Machines. The main products are Fluid Bed series, drying and granulating machine etc., which are mainly used in the fields of pharmaceutical, food, health care products and feed.
SNYNXN owns certificates of GMP, CE, SGS, ISO9001, AAA etc. With good quality and professional aftersales service, we enjoy high reputation among our customers over 120 countries and regions around the world.

Our Services

1.Your enquiry or questions will reponse once we receive it!
2.Providing technical data,high-definition pictures,flow chart that all you need
3.Supply the validation documents and certificates.
4.OEM/ODM is available.
5.Providing long-term after-sale service,door-to-door service and corporate training

Welcome to contact us for more about Low cost high quality pharmaceutical multi mill or pharmaceutical cone mill.
