Specializing in the production of pharmaceutical machinery and granulating drying equipment.
 |
| Place of Origin: | JIANGSU CHINA |
| Brand Name: | SNYNXN |
| Certification: | CE ISO GMP |
| Model Number: | GLP 200 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotaible |
| Packaging Details: | Film Wrapping, Wooden Case. |
| Delivery Time: | within 60 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100 set/year |
| Name: | Industrial Calcium Sodium Lignosulfonate Spray Dryer | Keywords: | Energy Saving, High Speed Spray Drying Machine |
|---|---|---|---|
| Working Process: | Continuous Feed-in | Evaporation Capacity: | 5-2000 (kg/h) |
| Inlet Temperature: | 140°C-350°C Adjustable | Max Rotation Speed: | 25000RPM |
| Core Components: | Pump, Motor, PLC | Applicable Industry: | Pharmaceutical, Fuel, Food, Beverage, Pigment, |
| Heating Source: | Steam, Electricity, Gas, Oil | Materials: | SUS304, SUS304L, SUS316, SUS316L |
| High Light: | Herbal Centrifugal Spray Dryer,2000kg/h Centrifugal Spray Dryer,Continuous pharmaceutical spray dryer OEM |
||
Description: Powder Spraying Dryer Machine
China Spray Drying Tower Emulsified Herbal Atomizer Drying Machine For Lignosulfonate Spray Dryer
Spray dryer is suitable for solution, suspension, slurry, paste material, etc. Liquid material is atomized to small fog drops. And fog drops contact with hot air directly in the drying tower. Moisture content is evaporated instantly. So spray dryer features high efficiency, high mass transfer area, and short drying time, in general it is 5~30 seconds. Operating temperature can be adjusted according to actual situation, in general inlet air temperature is 150~500°C. And its automation control degree is control, environment solution environment can be solved.
Application of GLP Spray Dryer:
Foodstuff industry: Amino acid and similar substance, flavoring, protein, starch, dairy products, instant coffee, fish powder, meat powder, tomato paste and so on.
Pharmaceutical Industry: Chinese patent medicine, agrochemical, antibiotics, medical drinking agent and so on.
Chemical industry: Organic catalyst, resin, synthetic washing powder, thiamin, dyestuff, intermediate of dyestuff, intermediate of dyestuff, white carbon black, graphite, ammonium phosphate and so on.
Ceramic industry: Magnesium oxide, kaolin, metallic oxide, dolomite and so on.
Technical parameters of Nozzle Type Centrifugal Spray Dryer:
|
Model Item |
GLP-25 | GLP-50 | GLP-100 | GLP-150 | GLP-200 | GLP-300 | GLP-500 | GLP-1000~2000 | ||
| Water evaporation(kg/h) | 25 | 50 | 100 | 150 | 200 | 300 | 500 | According to actual situation | ||
| Diaphragm pump | Power (Kw) | 0.35 | 4 | 7.5 | 11 | 15 | 22 | 30 | ||
| Pressure (Mpa) | It can be regulated from 0.6-5. In general, it is 1-3 | According to actual situation | ||||||||
| Heating source | Electricity | Electricity + steam | Hot air furnace | |||||||
| Diameter of tower (mm) | 1300 | 1800 | 2400 | 2600 | 2800 | 3200 | 3800 |
According to actual situatio |
||
Our Factory
SNYNXN is specialized in design, development, manufacture and sale of pharmaceutical, food, chemical extracting and drying equipments for more than 20 years. Our products include Dryer, Granulator, Mixer, Crusher, Evaporator and distiller etc.
Looking to the future with a commitment to design innovation and quality products, supported by an outstanding level of customer service. The unexcelled quality medical machinery can be easily obtained from us because we maintain the quality and standard of our products from incoming raw materials to the finished products.
Our company follows strict quality controls and various systematic procedures. We take utmost care of quality at every stage of the manufacturing process. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our Team is full of experienced and qualified professionals, who have sound knowledge about the quality of our medical machinery. Our products are far sold to Europe, U.S.A., and the southeast Asia. They are well received by customers both at home and abroad.
Pre-sales Service:
1. Inquiry and consulting support
2.Sending machine video for reference
3.Testing machine before delivery according to requirements.
4.View our Factory
Help training customer operation machine
Solve the customer's problem when machines in use through online video
The large equipment or complex machine, appointed engineer overseas service.
Contact Person: Salin Chen
Tel: +86-13961601352
