Specializing in the production of pharmaceutical machinery and granulating drying equipment.
 |
| Place of Origin: | JIANGSU CHINA |
| Brand Name: | SNYNXN |
| Certification: | CE, GMP, ISO 9001, AAA, SGS |
| Model Number: | DW1.2*10 |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 30000 |
| Packaging Details: | Standard Export Packing in Wooden case |
| Delivery Time: | IN 60 DAYS |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union |
| Supply Ability: | 100 SETS/YEAR |
| Machine Type: | Drying Equipment | Process Materials: | Fruit Vegetable Seaweed Pepper Herb Chilli Coconut |
|---|---|---|---|
| Keywords: | Dryer, Dehydrator, Dehumidifier | Applicable Industry: | Food Plant, Farms, Plastic Resin Manufacturing |
| Operation Temperature: | 50℃-140℃ | Steam Pressure: | 0.2Mpa-0.8Mpa |
| Cycle Time: | 0.2-3h | Conveyor Belt Width: | 1.2m, 1.6m For Choice |
| Conveyor Belt Length: | 8m, 10m, Depending On Requirements | Construction Material: | Stainless Steel 304 / 316L, AS Required |
| Core Component: | Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine | Voltage: | 220V-380-410-460V |
| Service: | Online Support, Video Technical Support, Free Spare Parts | Warranty: | 2 Years For Core Components |
| High Light: | Tunnel Dehydrator Microwave Belt,Tunnel Dehydrator Microwave Belt Drying Equipment,10m Tunnel Dehydrator Microwave Belt |
||
Mesh Belt Dryer Machine Technical Parameters
| Type | DW-1.2-8 | DW-1.2-10 | DW-1.6-8 | DW-1.6-10 | DW-2-8 | DW-2-10 | DW-2-20 | |
| Quantity of unit | 4 | 5 | 4 | 5 | 4 | 5 | 10 | |
| Belt width(m) | 1.2 | 1.6 | 2 | |||||
| Length of drying section(m) | 8 | 10 | 8 | 10 | 8 | 10 | 20 | |
| Thickness of raw material(mm) | ≤60 | |||||||
| Operation temperature(°C) | 50-140 | |||||||
| Steam pressure(MPa) | 0.2-0.8 | |||||||
| Steam consume(kg/h) | 120-300 | 150-375 | 150-375 | 170-470 | 180-500 | 225-600 | 450-1200 | |
| Drying time(h) | 0.2-1.2 | 0.25-1.5 | 0.2-1.2 | 0.25-1.5 | 0.2-1.2 | 0.25-1.5 | 0.5-3 | |
| Drying strength(kg/h) | 60-160 | 80-220 | 75-220 | 95-250 | 100-260 | 120-300 | 240-600 | |
| Power equipped(kw) | 11.4 | 13.6 | 11.4 | 13.6 | 14.7 | 15.8 | 36.8 | |
| Overall dimensions | L(m) | 9.56 | 11.56 | 9.56 | 11.56 | 9.56 | 11.56 | 21.56 |
| W(m) | 1.49 | 1.49 | 1.9 | 1.9 | 2.32 | 2.32 | 2.32 | |
| H(m) | 2.3 | 2.3 | 2.4 | 2.4 | 2.5 | 2.5 | 2.5 | |
| weight(kg) | 4500 | 5600 | 5300 | 6400 | 6200 | 7500 | 140 | |
Application of Mesh Belt Dryer
The Industrial continuous mesh belt dryer machine is an industrial continuous drying equipment. It is widely used for chemical industry, foodstuff industry, pharmaceutical industry, construction materials industry, electronic industry and so on. Especially it is suitable for drying raw materials that are good in breathability and have the shape of pieces or strip of granule. It is also possible to dry the pasted raw materials such as filter cake after shaped through granulator or extruder.
Features of Conveyor Mesh Belt Dryer
1, Air quantity, heating temperature, materials staying time and feeding speed can be adjusted to achieve the best drying effect.
2, The equipment configuration is flexible, mesh belt washing system and materials cooling system can be used.
3, Most air is recycled to realize saving energy
4, The machine is equipped with unique air dividing apparatus, it makes the hot air distribute uniform better and guarantee the quality of products is constant.
5, Heating source can be steam, conduction oil,, electricity, coal (oil), or hot air furnace.
Our Factory
International high quality certification product chain
Manufacturer, more reasonable price
Solid technical support and after-sales service
Uphold the principle of “Customer Supreme”( Balance payment after equipments run normally)
Exports to more than 20 countries and regions, good customers feedback
One-stop service, customized exclusive project feasibility report
SNYNXN located in the birthplace of China drying equipment----Jiangyin City, Jiangsu Province which is 120km away from Shanghai city, with a comfortable environment and convenient transportation access.
SNYNXN is a professional manufacture of drying machine, which include Seaweed processing machine, Seaweed drying machine (Cottonii to carrageenan, Agar agar ), Spray dryer, Vegetable and fruit Belt dryer, Conveyor Belt Dryer, mesh belt dryer, Food ingredients spray dryer, Flavor spray dryer (Cocoa, Maltdextrin,Gum Acacia), Lab Spray dryer, Gelatin processing machinery, Gelatin drying machine (Hide and bone),Gelatin production line. we also deal in high-quality fermentation tank, Bright tank , Extraction tank, concentration tank , evaporator and etc.
We are sure that our high quality products and excellent services will be appreciated by the growing list of satisfied customers.
Contacting us is the first step to build a long and successful business relationship with us.
Pre-service:
1.We provide presales service in various forms, making investment budge, manufacturing, planning, so that customers can make a reasonable plan with less cost.
2.We will fist check customer’s goods and goods size, then we will recommend suitable wrapping machine to 100% suitable.
3.We will recommend and offer machine according to customer’s use and purchase budget.
Sale service
1. Ensure product with high quality and pre-commissioning before delivery; provide each manufacturing step photo for customer checking on time.
2.Testing the machine and making video for customer’s checking.
3. Delivery on time;
4.Provide full sets of documents as customer’s requirements.
After-sale service
1.We will guarantee the machine quality for 1 year.
2.We provide free training and answer customer's question on technology in time.
